| Engine |
|
| Type |
four-stroke, horizontal four-cylinder in-line engine,
liquid-cooled |
| Bore/stroke |
70,5 x 70 mm |
| Cubic capacity |
1092 cm3 |
| Max power |
100 PS (74 kW) at 7500 rpm |
| Max torque |
107 Nm at 5500 rpm |
| Compression ratio |
11,0 : 1 |
| Valves per cylinder |
4 |
| Valve control |
DOHC, using drive chain and cup tappets |
| Carburation system |
electronic injection, Bosch Motronic MA 2.2 |
| Engine lubrication |
wet sump |
|
|
|
| Power transmission |
|
|
| Clutch |
dry single plate |
| Number of gears |
5 |
| Gear selection |
dog-type gearbox (ratchet foot lever) |
| Gear ratios |
4,50 / 2,96 / 2,30 / 1,88 / 1,61 :1 |
| Rear wheel ratio |
1 : 2,81 |
| Bevel/crown wheel |
11 : 32 teeth |
|
|
|
| Electrical system |
|
|
| Alternator |
12 V / 700 W |
| Ignition |
electronic ignition Bosch Motronic MA 2.2 |
| Starter |
0,7 kW |
| Spark plugs |
Bosch XR 5 DC, Beru 12-5 DU |
|
|
|
| Suspension |
|
|
| Type of frame |
tubular space frame, engine serving as load-bearing
component |
| Front suspension |
telescopic fork with hydraulic shock absorber |
| Rear suspension |
BMW Paralever - swinging arm |
| Spring travel |
135 / 120 mm |
| Rims front |
2,50 x 18 MT H 2 |
| Rims rear |
3,00 x 17 MT H 2 |
| Tyres front |
110/80-VR 18 |
| Tyres rear |
140/80-VR 17 |
| Brakes front |
dual-disc brake � 305 mm |
| Brakes rear |
single disc brake � 285 mm |
|
|
|
| Dimensions and weights |
|
|
| Length x width x height |
2250 x 915 x 1450 mm |
| Wheel base |
1565 mm |
| Ground clearance |
125 mm |
| Tank capacity |
22 l |
| Unladen weight, full tank |
290 kg |
| Max permissible weight |
500 kg |
| Fuel consumption |
4,9 l / 100 km ( at constant 90 km/h) |
| Acceleration |
0 - 100 km/h 4,3 s |
| Top speed |
210 km/h |
|
|
|
|
|
