| ENGINE |
4-stroke, DOHC,
4-valve single, Liquid-cooled |
| DISPLACEMENT |
651cc |
| BORE X STROKE |
100.0 x 83.0mm |
| COMPRESSION
RATIO |
9.5:1 |
| CARBURETION |
Keihin CVK40 |
| IGNITION |
Electronic CDI |
| LENGTH |
86.8 in. |
| WIDTH |
37.0 in. |
| HEIGHT |
53.0 in. |
| WEIGHT |
337 lbs. |
| GROUND CLEARANCE |
9.4 in. |
| FRAME |
Semi-double cradle,
high-tensile steel |
| WHEELBASE |
58.9 in. |
| FUEL CAPACITY |
6.1 gal. |
| SEAT HEIGHT |
35.0 in. |
| TRANSMISSION |
5-speed |
| FINAL DRIVE |
N/A |
| SUSPENSION |
Front: 38mm,
leading-axle air-adjustable fork and preload, 9.1 in. travel
Rear: UNI-TRAK single-shock system, 5-way preload and 4-way
rebound damping, 9.1 in. travel |
| BRAKES |
Front/Rear:
Hydraulic disc/Disc |
| TIRES |
Front: 90/90 x 21
Rear: 130/80 x 17 |
|
